RS60 Single Spring Elastomer Bellows Seal

Add to wishlist
Categories: ,

Description

FEATURES & BENEFITS
Single Spring, elastomer bellows seal
Compact
Full convolution bellows gives maximum flexibility
Pre-assembled for easy installation
Common to many commercial & domestic pumps
STANDARD MATERIALS OF CONSTRUCTION
Faces
Carbon Graphite (Resin Impregnated), Phenolic Carbon, Silicon Carbide
Elastomers
Buna, Viton®, Neoprene, EPDM
Metallurgy
304, 316
OPERATING LIMITS
Pressure
to 75 PSI, 5.2 Bar
Temperature
-40°F to +400°F
